FOXCONN 915P7AC-8KS, 915P/ICH6, PCIe x16, DualChannel DDR400, SATA, USB2.0, GLAN, sc775

Executive motherboard designed for Intel Pentium 4 processors and Celeron D to 775th cap SocketThe maximum memory throughput guarantees dualchannel memory controller with four slots for up to4 GB of memory type DDR.Orbis also includes gigabit network card, 8-channel sound card and controller of the three channels IDE ports and four Serial ATA.For further expansion offers a PCI Express x16, two PCI Express x1 and three PCI slots.To connect peripheral devices are available up to eight USB ports, serial and parallel port.

The parameters and specifications:

Čipset:
Intel 915th + ICH6

CPU:
Socket 775, Intel Pentium 4
Support for Intel processors Prescott and Celeron D
Support for Hyper-Threading
FSB 533 / 800 MHz

Memories:
Dual controller DDR 266 / 333 / 400
4 slots, max4 GB unbuffered

Controllers:
1 x ATA/100
2 x ATA/133
4 x SATA/150

Sound card:
8-channel High Definition (Realtek)

Network card:
Gigabit Ethernet 10 / 100 / 1000 Mbit / s (Broadcom)

Extension slots:
1 x PCI Express x16
2 x PCI Express x1
3 x PCI

Inputs and outputs:
2 x PS / 2
1 x RJ-45
4 x USB 2nd0
1 x Line-in / line-out / mic (audio)
1 x parallel port (SPP / ECP / EPP)
1 x serial port (16550-compatible UART)
1 x S / PDIF

Dimensions:
Format ATX
305 x 245 mm

Warning:Slot Socket 775 requires a professional assembly!The damage caused by improper treatment does not guarantee.We recommend that you get a computer to compile our service department.
