Seasonic G Series 450W
Don't like the alternatives? Choose from the full product list
Seasonic G Series 450W
Seasonic G Series power supply units are 80 Plus Gold certified, which is a certification awarded to power supply units with efficiency over 87%. The ATX (revision 2.3) unit has a 450 W maximum power output and features the obligatory active PFC. The intelligent S2FC thermal circuit system (Smart & Silent Fan Control) monitors the temperature and adjusts the fan speed to keep the optimal balance between cooling and noise levels. The unit’s high-quality capacitors are manufactured in Japan, guaranteeing longer service life than other power supply series.
Specifications:
Basic information:
Power output: 450 W
Efficiency: 80 Plus Gold certified (efficiency over 87%)
Revision: ATX 2.3
PFC: Active
Cooling:
Fan: 120 mm, silent, automatic speed control via S2FC (Smart & Silent Fan Control)
Max. power:
+3.3 V - 20 A
+5 V - 20 A
+12 V - 37 A
-12 V - 0.3 A
+5 VSB - 2.5 A
Connectors:
1x ATX 20+4 pin
1x EPS12V 4+4 pin
2x PCI-Express 6 +2 pin
5x Molex
6x SATA
2x FDD
Safety features:
OVP - Over Voltage Protection
UVP - Under Voltage Protection
OCP - Over Current Protection
OPP - Over Power Protection
OTP - Over Temperature Protection
SCP - Short Circuit Protection
Dimensions:
150 x 86 x 160 (width x height x depth)
Specifications
Performance and format
Equipment
Efficiency
Connectors
Cooling system
Dimensions
Sea Sonic Europe BV, Rietveld 7, 5258 ED Berlicum, Netherlands [email protected]
Specifications can be changed without notice. Images are for illustrative purposes only.
